Engine & Drivetrain
| Engine Capacity | 2 755 cc |
| Engine Layout | inline |
| Cylinders | 4 |
| Forced Induction Device | turbocharger |
| Fuel Type | diesel |
| Transmission | automatic |
| Number of Gears | 6 |
| Gearbox Details | automatic |
| Drive Wheels | rear |
| Engine Position | front |
Safety
| ABS | ✓ Standard |
| Brake Assist | ✓ Standard |
| Stability Control | ✓ Standard |
| Traction Control | ✓ Standard |
| Airbag Count | 2 |
| Driver Airbag | ✓ Standard |
| Passenger Airbag | ✓ Standard |
Features & Technology
| Air Conditioning | ✓ Standard |
| Bluetooth | ✓ Standard |
| USB Port | ✓ Standard |
| Auxiliary Input | ✓ Standard |
| Multi-Function Steering Wheel | ✓ Standard |
| Central Locking | ✓ Standard |
| Park Distance Rear | ✓ Standard |
| Park Distance Front | ✓ Standard |
| Reversing Camera | ✓ Standard |
| Electric Windows | ✓ Standard |
| On Board Computer | ✓ Standard |
| Power Steering | ✓ Standard |
| Daytime Running Lights | ✓ Standard |
| Fog Lamps Rear | ✓ Standard |
| Auto Headlamps | ✓ Standard |
| Electric Folding Mirrors | ✓ Standard |
| Auto Dim Interior Mirror | ✓ Standard |
| Metallic Paint | ○ Optional |
| High Level Brake Light | ✓ Standard |
| Power Socket 12v | ✓ Standard |
| Brake Hazard Lights | ✓ Standard |
| Tyre Front | 215/70 R16 C |
| Tyre Rear | 215/70 R16 C |
Dimensions & Weight
| Length | 5 265 mm |
| Width | 1 950 mm |
| Height | 1 990 mm |
| Wheelbase | 3 210 mm |
| Ground Clearance | 176 mm |
| Kerb Weight | 2 185 kg |
| Gross Vehicle Mass | 3 300 kg |
| Doors | 4 |
| Seats | 3 |
| Body Type | panel van |
| Turning Circle | 11 m |
Off-Road Capability
| Approach Angle | 15,2 ° |
| Departure Angle | 15,4 ° |
| Load Capacity | 890 kg |
| Towing Capacity | 1 400 kg |
Warranty & Service
| Warranty Period | 3 |
| Warranty Distance | 100 000 km |
| Service Plan | ✓ Standard |
| Service Plan Years | 9 yr |
| Service Plan Distance | 90 000 km |
| Service Intervals | 10000 |
Compare Toyota Quantum Against Rivals
Frequently Asked Questions
What is the price of the Toyota Quantum 2.8td LWB A/T F/C P/V?
The Toyota Quantum 2.8td LWB A/T F/C P/V is priced from R754 400 in South Africa. That's the recommended retail price for this variant. Dealer-fitted accessories, delivery charges and on-the-road costs will add to that. Compare all Toyota Quantum variants and their prices to find the best fit for your budget.
What is the towing capacity of the Toyota Quantum 2.8td LWB A/T F/C P/V?
The Toyota Quantum has a braked towing capacity of 1400 Kg. Unbraked trailer limits are lower - check the owner manual for the exact figure. Always ensure your trailer and tow vehicle combination stays within the legal rated capacity.
How much power does the Toyota Quantum 2.8td LWB A/T F/C P/V have?
The Toyota Quantum produces 115 kW of power and 420 Nm of torque from its 2755 cc diesel engine, driving the rear wheels. That torque figure determines real-world pulling power and performance.
What warranty and service plan does the Toyota Quantum 2.8td LWB A/T F/C P/V come with?
The Toyota Quantum comes with a 3 year / 100 000 km warranty. A service plan covering 9 services (over 90 000 km) is included. Services are due every 10 000 km.
